Laparoscopic left colectomy: surgical technique

Introduction

A true left colectomy is considered to be resection of the mid-transverse colon to the descending/sigmoid junction, though a standard sigmoid colectomy is a much more common surgical procedure. The distal extent of the descending or left colon does not have a definitive landmark. However, the descending colon lacks serosa on the posterior aspect and it is considered to become the sigmoid colon when it detaches from the lateral abdominal wall and becomes an entirely intraperitoneal organ again. The distal aspect of the sigmoid colon is the area where the taenia fuses together (1). Transection margins are dictated by the disease process, where proper oncologic margins are needed in cancer surgery, and the resection typically from healthy descending colon, to the top of the rectum in a diverticulitis case.

The most common indication for left colectomy is colon cancer (2,3). Other indications for resection include diverticulitis (4), ischemic colitis (5), segmental Crohn’s disease (6). The work-up also depends on the pathology, but normally consists of blood work, cross sectional imaging and colonoscopy. In our institution, patients receive a pre-operative package that consists of multimodal analgesia, dextrose containing drinks (7-9), mechanical bowel prep and oral antibiotics to facilitate an enhanced recovery protocol.

The aim of this manuscript is to detail the pre-operative, peri-operative and post-operative care of a patient undergoing a left colectomy for a variety of diseases. The patient selection and work-up for colon cancer, diverticulitis, polyps and colonic Crohn’s disease will be discussed. The technical aspects, with tips and tricks, will also be presented in detail.

Patient selection and work-up

Patient selection

Left colectomy is indicated for patients with a distal transverse or descending colon cancer without evidence of distant metastatic disease. Some patients with liver metastases can be considered for resection. Other indications include ischemic colitis, colonic polyps not amenable to endoscopic resection, diverticulitis and segmental Crohn’s disease.

Patients with colorectal cancer and liver metastasis can be considered for surgery in the pre-operative setting, though they should be discussed in a multidisciplinary conference. The goal of the operation is to remove the tumor completely with at least a 5cm margin proximally and distally. An R0 resection is associated with good long-term outcomes (10-12). Ischemic colitis is an indication for operative intervention when associated with peritonitis on physical exam, significant bleeding or fulminant colitis (5). Colectomy is indicated if polyps are unable to be completely removed during endoscopy due to the risk of harboring malignancy (13). The management of uncomplicated diverticulitis has evolved, and the decision for colectomy is made on an individual basis (4). Segmental colonic Crohn’s disease is uncommon, but does occur. Complications, such as stricture, perforation, fistula formation, intractable pain, failure of medical therapy, are indications for operative intervention (6).

Pre-operative preparation

All patients having an elective operation undergo a complete history and physical examination. Adjunct testing, such as blood tests, additional imaging or cardiac testing, is performed when indicated. The patients are also seen by a wound ostomy nurse for ostomy teaching and stoma marking if appropriate, though this is rarely needed in the elective setting.

We use a formal enhanced recovery protocol (14) and a mechanical bowel preparation in combination with oral antibiotics. The use of mechanical bowel prep and oral antibiotics has had much controversy over the years. Recent literature has shown decreased rates of surgical site infection, wound dehiscence, ileus and anastomotic leak (15,16).

The necessary equipment should be available to perform a laparoscopic equipment as described (Table 1).

Procedure

Positioning

The patient is placed in the lithotomy position with both arms tucked and the thighs positioned at no more than a 10-degree angle to the torso. A beanbag or similar device is used to secure the patient to the table, and care should be taken to avoid any pressure points. We use a 5 mm port above the umbilicus, a 5 mm right upper quadrant port, a 5 mm left sided port, and a 12 mm right lower quadrant port, typically placed 2 fingerbreadths medial and 2 fingerbreadths cephalad to the anterior superior iliac spine.

Operative details

Vascular pedicle isolation and transection

A medial to lateral approach is generally the preferred approach unless the surgeon is unable to safely identify the anatomy. This approach allows the surgeon to safely separate the left colonic mesentery from the retroperitoneum and protect the ureter, retroperitoneal blood vessels, and sympathetic nerves (Figure 1). The exposure is facilitated by reflecting the small bowel out of the pelvis. This is accomplished with a combination of Trendelenburg positioning and rotating the bed with the right side down.

Figure 1 Medial to lateral dissection of the inferior mesenteric artery pedicle (17). Available online: http://www.asvide.com/article/view/29869

We can identify the right ureter, the sacral promontory, and the inferior mesenteric artery (IMA) pedicle from this view. Once the pedicle is placed on a gentle stretch, a mesenteric window is created with cautery. The pedicle is lifted upwards and a gentle blunt dissection in the proper congenital fusion plane between the mesentery and retroperitoneum. Once the mesentery is lifted off the retroperitoneum, the left ureter and gonadal vessels are swept away from the pedicle. We typically do a high ligation of the IMA regardless of the indication for surgery, as it allows for excellent visualization of the tissue planes. We prefer an energy device to transect the mesentery, but a vascular load stapler is also acceptable. The surgeon should have a grasper ready to gently occlude the pedicle, should it bleed, thus allowing a controlled application of an endoloop/clip if necessary.

Sigmoid colon mobilization

If the dissection was done correctly from the medial approach, there should not just be a purple and thin appearance to the peritoneum laterally (Figure 2). The colon is grasped with an atraumatic bowel grasper and retracted medially. The colon is mobilized off the retroperitoneum by dissecting through this thin peritoneal layer. The location of the ureter, gonadal vessels and iliac vessels are confirmed and the sigmoid colon is mobilized until it is a midline structure. In the same manner, the remainder of the descending colon is mobilized off the lateral retroperitoneal attachments.

Figure 2 Splenic flexure mobilization (18). Available online: http://www.asvide.com/article/view/29870

Splenic flexure mobilization

In many instances, simple mobilization of the descending colon is not enough to achieve a tension free anastomosis. In this case, the splenic flexure should be mobilized, and this can easily be accomplished laparoscopically. Typically, the lateral dissection continues, rolling the colon mesentery medially away from Gerota’s fascia over the kidney. The renocolic, splenocolic, and phrenicocolic attachments are released. The gastrocolic ligament is then taken down to enter the lesser sac and mobilize the omentum off the transverse colon until the midline or middle colic vessels are reached depending on the indication for the operation (Figure 3). If the colon still does not reach, ligation of the IMV near the inferior border of the pancreas may be needed, but this is rarely necessary outside of low rectal cancer surgery.

Figure 3 Transection of the rectum (19). Available online: http://www.asvide.com/article/view/29871

Distal transection

Lastly, the remaining peritoneal attachments are divided, taking care to protect both ureters and the sympathetic nerves at the sacral promontory. An energy device is used to thin out the rectal mesentery to prepare the rectum for a transection. The rectum is transected with a laparoscopic linear cutter stapler, ideally in one single firing (Figure 4).

Figure 4 Colorectal anastomosis (20). Available online: http://www.asvide.com/article/view/29872

A Pfannenstiel incision for extraction is preferred due to its lower risk of incisional hernia formation and wound complications (21-23). The colon is then exteriorized and the proximal transection margin is identified. The anvil of an EEA stapler is inserted into the proximal cut end and secured with a purse string. The colon is placed back into the abdomen and insufflation is reestablished. An assistant inserts an EEA stapler into the anus and up to the apex of the rectal segment. The anvil is then docked onto the spike. It is important to confirm correct orientation of the colon by using the cut edge of the mesentery. The stapler is then closed, fired and removed. The stapler “donuts” are removed and examined to ensure an intact staple line. Finally, a leak test is performed by filling the pelvis with water and performing sigmoidoscopy to ensure an airtight anastomosis (Figure 5).

Figure 5 Hand-assisted technique in a difficult diverticulitis case (24). Available online: http://www.asvide.com/article/view/29873

After the leak test, the abdomen is irrigated and adequate hemostasis is confirmed. Pneumoperitoneum is allowed to deflate and the 12 mm port site is closed in a figure-of-eight fashion. The skin is closed with interrupted, absorbable sutures.

Hand-assisted laparoscopic surgery

In a select subset of patients, a totally laparoscopic approach may not be able to be safely performed. These operations could be amenable to a hand-assisted approach rather than converting to open. Hand-assisted laparoscopy gives the added benefits of tactile feedback, additional dissection and helps facilitate retraction. This approach has been shown to be helpful in cases where dense adhesions, unresolved diverticular phlegmon, bulky tumors and inability to gain adequate exposure are encountered (25,26).

Post-operative management

Post-operatively, the patients are placed on an enhanced recovery pathway. The orogastric tube is removed in the operating room prior to awakening from anesthesia. Following the operation, the patient is given a clear liquid diet and intravenous fluids. Their diet is normally advanced to a low residue diet on post-operative day 1. Intravenous fluids are discontinued once the patient is tolerating adequate oral intake. Pain is controlled in multimodal fashion. Immediately post-operatively, intermittent intravenous narcotics control pain or a patient-controlled anesthesia (PCA) device is ordered. They are given scheduled acetaminophen, gabapentin, famotidine and ketorolac, if appropriate. Pain control is transitioned to oral medications as their diet is advanced. They are also given the gastrointestinal specific opioid antagonist alvimopan, which is continued until discharge or to a maximum of 7 days, whichever occurs first (27). A Foley catheter remains post-operatively and is normally discontinued on post-operative day 1. Patients are usually discharged on POD 1 or 2.

Acknowledgments

Funding: None.

Footnote

Provenance and Peer Review: This article was commissioned by the Guest Editors (Michael J Stamos and Mehraneh Dorna Jafari) for the series “Laparoscopic Colon Surgery” published in Annals of Laparoscopic and Endoscopic Surgery. The article has undergone external peer review.

Conflicts of Interest: The series “Laparoscopic Colon Surgery” was commissioned by the editorial office without any funding or sponsorship. IM Paquette is a consultant for Ethicon. MC Morris has no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this manuscript and any accompanying images.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Amin MB, Edge S, Greene F, et al. editors. AJCC cancer staging manual. Eighth edition. Chicago IL: American Joint Committee on Cancer, Springer, 2017.
2. Clinical Outcomes of Surgical Therapy Study Group. A comparison of laparoscopically assisted and open colectomy for colon cancer. N Engl J Med 2004;350:2050-9. [Crossref] [PubMed]
3. Colon Cancer Laparoscopic or Open Resection Study Group. Survival after laparoscopic surgery versus open surgery for colon cancer: long-term outcome of a randomised clinical trial. Lancet Oncol 2009;10:44-52. [Crossref] [PubMed]
4. Meyer AA, Sadiq TS. What Are the Indications for Resection After an Episode of Sigmoid Diverticulitis? Adv Surg 2015;49:1-13. [Crossref] [PubMed]
5. Brandt LJ, Boley SJ. AGA technical review on intestinal ischemia. American Gastrointestinal Association. Gastroenterology 2000;118:954-68. [Crossref] [PubMed]
6. Strong S, Steele SR, Boutrous M, et al. Clinical Practice Guideline for the Surgical Management of Crohn's Disease. Dis Colon Rectum 2015;58:1021-36. [Crossref] [PubMed]
7. Awad S, Varadhan KK, Ljungqvist O, et al. A meta-analysis of randomised controlled trials on preoperative oral carbohydrate treatment in elective surgery. Clin Nutr 2013;32:34-44. [Crossref] [PubMed]
8. Smith MD, McCall J, Plank L, et al. Preoperative carbohydrate treatment for enhancing recovery after elective surgery. Cochrane Database Syst Rev 2014;CD009161 [PubMed]
9. Lidder P, Thomas S, Fleming S, et al. A randomized placebo controlled trial of preoperative carbohydrate drinks and early postoperative nutritional supplement drinks in colorectal surgery. Colorectal Dis 2013;15:737-45. [Crossref] [PubMed]
10. Andres A, Mentha G, Adam R, et al. Surgical management of patients with colorectal cancer and simultaneous liver and lung metastases. Br J Surg 2015;102:691-9. [Crossref] [PubMed]
11. Mise Y, Aloia TA, Brudvik KW, et al. Parenchymal-sparing Hepatectomy in Colorectal Liver Metastasis Improves Salvageability and Survival. Ann Surg 2016;263:146-52. [Crossref] [PubMed]
12. Pulitanò C, Bodingbauer M, Aldrighetti L, et al. Liver resection for colorectal metastases in presence of extrahepatic disease: results from an international multi-institutional analysis. Ann Surg Oncol 2011;18:1380-8. [Crossref] [PubMed]
13. Bertelson NL, Kalkbrenner KA, Merchea A, et al. Colectomy for endoscopically unresectable polyps: how often is it cancer?. Dis Colon Rectum 2012;55:1111-6. [Crossref] [PubMed]
14. Jung AD, Dhar VK, Hoehn RS, et al. Enhanced Recovery after Colorectal Surgery: Can We Afford Not to Use It? J Am Coll Surg 2018;226:586-93. [Crossref] [PubMed]
15. Klinger AL, Green H, Monlezun DJ, et al. The Role of Bowel Preparation in Colorectal Surgery: Results of the 2012-2015 ACS-NSQIP Data. Ann Surg 2017; [Epub ahead of print]. [Crossref] [PubMed]
16. Kiran RP, Murray AC, Chiuzan C, et al. Combined preoperative mechanical bowel preparation with oral antibiotics significantly reduces surgical site infection, anastomotic leak, and ileus after colorectal surgery. Ann Surg 2015;262:416-25; discussion 423-5. [Crossref] [PubMed]
17. Morris MC, Paquette IM. Medial to lateral dissection of the inferior mesenteric artery pedicle. Asvide 2019;6:029. Available online: http://www.asvide.com/article/view/29869
18. Morris MC, Paquette IM. Splenic flexure mobilization. Asvide 2019;6:030. Available online: http://www.asvide.com/article/view/29870
19. Morris MC, Paquette IM. Transection of the rectum. Asvide 2019;6:031. Available online: http://www.asvide.com/article/view/29871
20. Morris MC, Paquette IM. Colorectal anastomosis. Asvide 2019;6:032. Available online: http://www.asvide.com/article/view/29872
21. Benlice C, Stocchi L, Costedio MM, et al. Impact of the Specific Extraction-Site Location on the Risk of Incisional Hernia After Laparoscopic Colorectal Resection. Dis Colon Rectum 2016;59:743-50. [Crossref] [PubMed]
22. Lee L, Mappin-Kasirer B, Sender Liberman A, et al. High incidence of symptomatic incisional hernia after midline extraction in laparoscopic colon resection. Surg Endosc 2012;26:3180-5. [Crossref] [PubMed]
23. Orcutt ST, Balentine CJ, Marshall CL, et al. Use of a Pfannenstiel incision in minimally invasive colorectal cancer surgery is associated with a lower risk of wound complications. Tech Coloproctol 2012;16:127-32. [Crossref] [PubMed]
24. Morris MC, Paquette IM. Hand-assisted technique in a difficult diverticulitis case. Asvide 2019;6:033. Available online: http://www.asvide.com/article/view/29873
25. Jadlowiec CC, Mannion EM, Thielman MJ, et al. Evolution of technique in performance of minimally invasive colectomies. Dis Colon Rectum 2014;57:1090-7. [Crossref] [PubMed]
26. Midura EF, Hanseman DJ, Davis BR, et al. Laparoscopic sigmoid colectomy: Are all laparoscopic techniques created equal? Surg Endosc 2016;30:3567-72. [Crossref] [PubMed]
27. Adam MA, Lee LM, Kim J, et al. Alvimopan Provides Additional Improvement in Outcomes and Cost Savings in Enhanced Recovery Colorectal Surgery. Ann Surg 2016;264:141-6. [Crossref] [PubMed]
