Sleeve gastrectomy and its modifications

Cem Emir Guldogan1, Omer Vefik Ozozan2, Mehmet Mahir Ozmen1

1İstinye University School of Medicine, Liv Hospital Ankara, Ankara, Turkey; 2İstinye University School of Medicine, Bahçehir Liv Hospital, İstanbul, Turkey

Contributions: (I) Conception and design: All authors; (II) Administrative support: All authors; (III) Provision of study materials or patients: All authors; (IV) Collection and assembly of data: All authors; (V) Data analysis and interpretation: All authors; (VI) Manuscript writing: All authors; (VII) Final approval of manuscript: All authors.

Correspondence to: Cem Emir Guldogan, MD, Asst. Professor, FEBS. Bestekar Sokak No. 8 Kavaklıdere, Ankara, Turkey. Email:

Abstract: Initially sleeve gastrectomy (SG) was performed as an open procedure in 1988, known as Hess and Marceau’s technique, which is actually the first stage of the bilio-pancreatic diversion-duodenal switch (BPD-DS). It was proposed in 1993 as a single weight-loss procedure defined by Johnston, later known as operation Magenstrasse and Mill. In 1999 Gagner was the first to describe laparoscopic SG technique. Therefore SG became popular and one of the most common bariatric surgery procedure in the world. The method has many technical differences. Unfortunately, there is still no strict standardization of the method. With the development of technology, robotic surgery has taken its place in bariatric surgery field. A lot of new studies on robotic SG (RSG) have recently been published. Also there are several technical conflict, such as distance from the pylorus, resection of greater curvature, size of the antrum, use of bougie, fundus resection, whether or not reinforce the staple line, identification and repair of the hiatus. There are also some contraindications for SG. Barrett’s esophagus is a one of them. These variations in the technique affect the complications and effectiveness of surgery. In this study, we aimed to discuss the development and modifications of SG steps of with the current literature review.

Keywords: Bariatric surgery; obesity surgery; laparoscopic sleeve gastrectomy (LSG); robotic sleeve gastrectomy (RSG); single incision sleeve gastrectomy; sleeve gastrectomy modifications; operative steps; controversies

Received: 02 February 2020; Accepted: 27 April 2020; Published: 20 July 2020.

doi: 10.21037/ales-20-30


Sleeve gastrectomy (SG), also called longitudinal gastrectomy, is performed with increasing frequency in the treatment of morbid obesity in recent years. The method is generally considered to be a totally restrictive technique because it reduces gastric capacity, but it also provides a decrease in post-prandial ghrelin levels. Ghrelin is secreted from the fundus. Gastric fundus contains more ghrelin per gram of tissue than the duodenum (1,2). In addition, Laparoscopic SG (LSG) does not cause malabsorption but increased intestinal motility, and the rate at which food reaches the small intestine, and thus affect circulating levels of other intestinal hormones (3). This consequently decreases the sensation of hunger. LSG has been the most common bariatric surgical procedure in many countries. But it is difficult to compare studies on preoperative preparation and outcomes because of the variations of technique (4).

Patient selection

LSG is very effective and useful for morbidly obese patients and patients with BMI greater than 50. It can be planned as the first stage procedure. It can also be safely performed in patients with comorbidities and awaiting for transplantation (5,6). SG has a shorter operative time than other gastric bypass procedures. It is really difficult to reach the biliary tract with gastric bypass methods, but there is no technical difficulty with SG. It may also be preferred in patients with diseases like Crohn and ulcerative colitis, or who need regular upper gastrointestinal system examination. It may be useful in patients who have undergone lower gastrointestinal system surgery and have small bowel adhesions. It is also recommended for the patients as gastric bypass can cause changes in serum levels of some kind of drugs. Many bariatric surgeons accept gastroesophageal reflux disease (GERD), Barrett’s esophagus as contraindications (7). None of the studies have shown the risk of Barrett’s conversion to high-grade dysplasia or adenocarcinoma after SG. SG can be performed in adolescents with severe comorbidities whose body mass index higher than 35. This is effective when compared to diet and exercise. It allows the healing or ameliorate of both somatic and physiological issues related with obesity (8-10). LSG has theoretical advantages, especially for this patient group. The incidence of surgical or non-surgical complications is lower in LSG than in gastric bypass. The need for mineral and vitamin supplements may be shorter in LSG groups than bypass groups. The main advantage of SG in adolescent obese patients is that it can be easily converted to other alternative methods in later years. We believe bariatric surgery for adolescent should be considered by a special adolescent bariatric. All patients must be informed about the technique of SG and accept the risks of operation. Patients should know that they will be on a long-term diet program and they should change their lifestyle.


Patient position

The patient was placed supine with the French position. Lower extremity compression is very important to avoid deep vein thrombosis. We use compression socks. Also compression devices can be used for prophylaxis. We use belts from the soles of the feet to fix the patient to the operation table.


In our practice, we prefer the closed method using Veress needle. It is in most cases placed from the supraumbilical region. We maintain intraabdominal pressure between 13 and 14 mmHg. For patients who cannot be placed safely, we use a 0 degree telescope and optic trocar. If necessary open (Hasson) technique can be used it is the safest method.

Insertion of trocars

In our practice, we usually use two 12 mm and one 10 mm trocar. However, extra trocars may be required in difficult situations. The first trocar is placed in the superior-lateral aspect of the umbilicus. We prefer 30° camera because it provides perfect visualization of the angle of His. We use two 12 mm ports placed in the right and left midclavicular line.

Liver retraction

We placed in Nathanson®’s retractor through a 5 mm incision. Then we retract the left lobe of the liver that also allows the visualization of the hiatus and vagus nerves (Figure 1). Then it is evaluated for any looseness or hiatus hernia (HH). If there is a HH, we usually perform crus repair after completion of SG.

Figure 1 Retraction of left liver lobe with the Nathanson’s retractor.

Dissection and mobilization of greater curvature

We always put a nasogastric (NG) tube to decompression the stomach. The NG tube should not be forgotten in the stomach after decompressing the stomach. It is essential to verify that the vessels located around the greater curvature are properly sealed (Figure 2). The greater curvature is freed from 4–6 cm proximal to the pylorus. Entering the lesser sac is easier here. Any 5 mm energy-based device of can be used. Sealing should be done close to the stomach (11,12).

Figure 2 Starting dissection on greater curvature.

Dissection near angle of His

All attachments between the fundus and the diaphragm should be divided (Figure 3); the fat pad should be dissected but should not resected. We should be avoided from the dissection of the GE junction. After totally mobilizing the greater curvature in the presence of HH, both crus dissected for repair after completion SG.

Figure 3 Left crura.

Creation of gastric tube

First, the placement of all tubes except the bougie into the stomach should be performed by the anesthesiologist. The bougie is then advanced to the first part of the duodenum and its alignment should be straight (Figure 4). We usually place it after the first stapler (Figures 5,6). There should be communication between the anesthesiologist and the surgeon, as forced placement may cause injury. Instead, an endoscope may be used to calibrate the sleeve formation. There are many different types of bougie ranging from 32–60 F to form the tube. We use 36 F bougie in our current practice. Technically, weight loss is not related with the bougie size (13,14). Using a thinner size bougie can provide more effective weight loss, but may result in higher stricture and leakage rates. The transection of the stomach starts 3–5 cm proximal to the pylorus. We usually use a 60 mm stapler extra thick cartridge (black) for first firing. The first stapler should be placed in from the right trocar tangential to the antrum and we should take care of closure the jaws. After the first firing, left trocar can used for the ongoing stapling. Usually 4–8 staplers are enough to complete the sleeve formation. Antrum is the thicker part of the stomach. The first two cartridges should be green or preferably black, the rest can be blue, purple or green. We recommend using black or green cartridges for the first two fires and purple cartridges for the other four fires. In our practice we usually prefer purple color cartridges (for the first two firings. Lateral traction of the stomach is essential to create a straight staple line. One of the most important point during transection is to avoid incisura angularis and remove the all fundus at a distance of 1 cm from the esophagus.

Figure 4 Placement of bougie with the atraumatic graspers.
Figure 5 First stapler firing.
Figure 6 Rotating stapler to check posterior stomach.

Hemostasis and reinforcement

Staple line reinforcement can be used to reduce bleeding and leaks and there are some techniques to support this line like over sewing, using buttressing material, fibrin glue along the staple line. Buttressing materials include glycol trimethyl carbonate copolymer, bovine pericardium or porcine small intestine submucosa can be used to decrease the bleeding rates from the staple line. But use of buttressing material is still controversial. As a result of our study, 145 patients underwent LSG; we used Tisseel® for 57 patients and Seamguard® for 73 patients. These reinforcement materials were effective methods to decrease staple line bleeding. Hospitalization, complications and drainage volumes were similar in both groups. Seamguard® was reduced operating time. Use of Tisseel® was decreased the hospital costs. And we can say both reinforcement techniques can be safely use during LSG (15). In our center, Seamguard® is used in patients with high BMI and using anticoagulants. It should be noted that the staples are not hemostatic and the staple line needs to be checked. Hemorrhage should be stopped with clips and sutures. Surgeon should be avoided from the thermal damage.

Leak test and extraction of specimen

In our practice the leak test is a routine test for all patients. We use methylene blue through the nasogastric tube (Figure 7). Also we use endoscopy to check the sleeve tube for leaks, bleeding and patency. The specimen can be extracted from 15 mm trocar (Figure 8). A suction drain (Jackson Pratt 14 F) is placed under the liver. We always close the fascia of the 15 mm trocars to avoid hernia occurrence and for skin closure we use subcutaneous Monocryl sutures.

Figure 7 Leak test with methylene blue.
Figure 8 Extraction of specimen.

Concomitant HH and reflux

HH and GERD treatment which can be emerged after SG operations and it is still very controversial. Nearly half of morbidly obese patients have GERD. Symptomatic GERD after SG is associated with increased relaxation of the lower esophageal sphincter and high intra-abdominal pressure. Prevalence of esophagitis and low incidence of esophageal and junctional adenocarcinomas are increased in morbidly obese patients compared to the general population (16). In a consensus meeting 83% of specialist surgeons decided that HH should be identified intraoperatively and, if present, repaired; 69% of surgeons participating in the 4th International LSG Consensus found that they were actively looking for and the 89% of surgeons said they would repair it if identified intraoperatively (4,5). In our current practice, we recommend that intraoperative HH repair when we detect HH preoperatively or perioperatively. After dissection of the large curvature is completed, the left crus should be exposed and the left and right crus should be repaired using non-absorbable sutures in the presence of HH. Meanwhile, a bougie or a preferred endoscope can be inserted. After SG decreased intra-abdominal pressure with weight loss helps to reduce the incidence rate of GERD. Symptomatic GERD and/or a large HH diagnosed preoperatively, care should be taken against LSG. Technically, if possible, gastric bypass methods may be recommended. In cases of reflux after LSG, the wrong surgical technique should be considered and most patients can be initially treated with proton pump inhibitors. If GERD symptoms persist, LSG can be converted to gastric bypass methods.

Banding the sleeve

This approach has been recommended to decrease dilatation of sleeve tube. However, many authors believe that routine use after LSG cannot be recommended. Adding a silastic ring or band around the sleeve tube has no proven benefit and may increase short and long-term morbidity. Banding the sleeve can only be evaluate with larger randomized controlled trials with the patient›s approval process (17,18).

Robotic SG (RSG)

RSG is being a popular surgical approach with many advantages such as high image quality and sensitivity. The learning curve and the high cost are the main drawbacks. For robotic surgery we use da Vinci Xi. We placed the patients in supine position for RSG. We placed endoscope port close to the umbilicus (2 cm laterally and 2 cm above). After pneumoperitoneum, the patients were placed in the reverse Trendelenburg position. We use a Nathanson retractor from the epigastrium in all cases. We place two 8 mm ports on both sides of the hypochondrium and place a 12 mm assistant port between the previous ports and the left side of the lateral abdominal region. EndoWrist instruments (Fenestrated Bipolar and Vessel Sealer) and robotic arms by connecting the ports, we begin the operation. The next steps are almost identical to the laparoscopic technique (Figures 9-14). In our study we compared the first 30 RSG cases with the last 30 laparoscopic cases and study revealed no significant difference between the groups in terms of complications, bleeding, leakage, stenosis, length of hospital stay, and weight loss (19). However, the duration of the operation and the amount of drainage were different. Robotic surgery has facilitated many interventions because of the better visibility of EndoWrist devices and higher maneuverability. Robotic surgical techniques have also been included in obesity surgery and have been shown to be more effective and provide excellent anastomosis and access to difficult areas in some complex bariatric procedures.

Figure 9 A 36 French bouige has been pushed through the pylorus to first part of duodenum.
Figure 10 After measuring the distance from the incisura the first stapler should be angled away from the incisura.
Figure 11 View of GASTRISAIL™ with firefly mode.
Figure 12 Detachment of posterior attachments.
Figure 13 Final view of gastric sleeve.
Figure 14 Jackson-Pratt drain placed near sleeve tube through right port.

Single port SG (SPSG)

SPSG procedure could performed with a single incision with limited range of movements. But extraction of specimen can be a problem without enlargement of incision. Last 10 years several series of SPSG have been published (20-22). The cosmetic benefit, less pain after surgery, hospital stay and fast return to work can be expected advantages of procedure (23,24). There are some difficulties and disadvantages like triangulation, dissection and exposure, and the need for liver retraction. The present studies show SPSG can be performed safely with similar intraoperative and postoperative morbidity compared to the LSG. Weight loss and comorbidities resolution at 1 year are was equivalent. Operative duration was longer in the SPSG group. In conclusion evaluation of the potential benefits of SPSG requires further evaluation by large, prospective, randomized studies.


SG decrease volume of stomach and that increase intragastric pressure. This is the reason of some patients have reflux after SG. N-sleeve starts with dissection and reduction of HH. Esophagus should be mobilized. Para esophageal space should be dissected. The greater curvature is freed from 4–6 cm proximal to the pylorus. Two non-absorbable sutures are used to close the HH and a bougie is inserted routinely. 360° valve of 3 cm is created by using silk and the wrap valve is fixed to the anterior part of the esophagus. Then SG should be performed as usual. There are some important technical points contrary to standard SG, we should be careful about ischemia of the gastric wall and not to stapling double the part of fundus. In a recent study, 3 months after N-sleeve, 76% of the patients were asymptomatic and there was no need to use proton pump inhibitor; 12% of the patients were still have complaining with reflux symptoms (25,26).
