A review of sigmoid volvulus and natural orifice specimen extraction surgery

History and feasibility

Minimally invasive methods to treat sigmoid volvulus were initially laparoscopy-assisted colon resections (1-3). Minimally invasive methods are preferred in sigmoid volvulus patients, most of whom are elderly, because of their advantages, such as fewer wound complications, less pain, and a shorter hospital stay (4). Since it was first published, laparoscopic resection has gained increasing acceptance for the treatment of benign and malignant diseases of the sigmoid colon (5).

The aim of minimally invasive surgery is to perform the surgery with the least possible incision; however, an extra incision is still needed to remove the specimen. Fewer incisions in colon resection surgeries and the use of natural orifices for specimen extraction, such as in transanal and transvaginal approaches, have been described, and their popularity is increasing (6,7). In the literature, specimen extraction from the natural orifice after laparoscopic surgery for sigmoid volvulus is rare, and a total of 28 cases of sigmoid volvulus in 7 publications have been reported to date (8-14) (Table 1). We recorded eight patient experiences [Gaziantep University Ethics Committee (2020/178) and registered in an international database (ClinicalTrials.gov NCT04740619)] that are not yet reported. In addition, there are cases of sigmoid volvulus in which the colon is everted and resection from the anal region is completed after intraabdominal proximal transection (16). One case of sigmoid volvulus was reported in which the specimen was removed transanally after resection with robotic surgery, which is widely used (8).

Potential benefits

The greatest advantage of natural orifice surgery is that no additional incision is needed for specimen extraction. This technique, which improves the aesthetic results and/or increases the comfort of the patients, has been widely accepted by surgeons. Improved postoperative pain control, shorter time to first bowel movement, fewer incisional complications, shorter hospital stays, and more favorable cosmetic results have been demonstrated with natural orifice surgery (17). It has been shown that natural orifice surgery can be safely applied to both benign diseases and malignant diseases (18). In sigmoid volvulus, because the colon does not contain a mass and has a long and narrow mesentery, the specimen diameter is small, which presents an advantage for natural orifice surgery.

In patients with sigmoid volvulus, the dilated colon lumen facilitates specimen extraction by the transanal route; the transvaginal route is less often preferred. In the literature, only one case has been reported in which natural orifice transluminal endoscopic surgery (NOTES) was performed transvaginally with a single port (15).

Patient factors and selection

The feasibility of natural orifice specimen extraction surgery (NOSES) is related to two factors: one factor is the patient, and the other is the specimen. A patient factor is associated with body mass index (BMI) and gender, while the specimen factor is associated with maximum tumor diameter and size. BMI <30 kg/m² and low comorbidity can be considered necessary conditions for elective surgery (19). If the patient is a woman, the transvaginal route can be employed. While the transvaginal route is recommended for larger masses, the transanal route is recommended for smaller masses, as the colon lumen is small (20). It may be hypothesized that the wider pelvis diameter in women could increase the success of natural orifice surgery; however, similar results have been reported in both men and women when comparing laparoscopic colorectal resections (21).

Surgical technique

In the literature, transanal specimen extraction by eversion was first described in a 10-year-old boy with sigmoid volvulus in 2010 (16). Single-port laparoscopy and pure transvaginal surgery were described in an 84-year-old female patient with sigmoid volvulus in 2014. Transanal specimen removal was described 5 years later, in a 22-year-old female patient with sigmoid volvulus (11,15). In this patient, Sia et al. resection was performed after tying the distal part of the specimen with nylon tape, and the specimen was removed through the colon (11). In contrast, in definitive surgery for patients with sigmoid volvulus caused by Hirschsprung’s disease, both resection and specimen extraction can be achieved with transanal pull-through (22). In our clinical experience, after performing the resection in the abdomen with the help of a stapler, the stapler line in the proximal rectum is opened and the specimen is removed in this way. The circular stapler anvil is taken into the abdomen transanally. After the anvil is placed at the distal end, the proximal opening is closed with a linear stapler, and anastomosis is made with a circular stapler.

Step by step surgical technique

Informed consent was obtained from patients and elective operations were scheduled after successful derotation. Because the patients were operated on after endoscopic derotation, only a rectal enema was performed before the surgery. Subcutaneous low molecular weight heparin (0.1 mg/kg) was administered preoperatively. A single dose of third-generation cephalosporin[1 g, intravenous injection (IV)] and metronidazole (500 mg, IV) was administered one hour before the operation for antibiotic prophylaxis. The patient was taken to the operating table in the lithotomy position and fixed to the table to prevent falling. General anesthesia was then administered. An incision was made under the umbilicus to place a 12 mm trocar. A pneumoperitoneum was created using a Veress needle. A total of four trocars were used. The 30-degree camera trocar was inserted when intra-abdominal pressure reached 12–15 mmHg. Then, two main 5 and 12 mm trocars were placed in the right paracolic area. An assistant trocar was placed in the left paracolic area. The sigmoid colon was resected, preserving the mesentery, toward the distal of the colon, descending to 5 cm above the peritoneal reflection. The staple line on the distal rectal stump was opened, and the stump walls were held open with a grasper (Figure 1). Resection of the sigmoid colon was aided by a clamp inserted through the anal canal and into the lumen. The specimen was retrieved through a transanal approach (Figure 2). A 31–33 mm circular stapler was placed via the anus, then the anvil was taken into the abdomen and the shaft removed. The open rectal stump was closed again with a stapler. The anvil was inserted at the end of the proximal colon through the stapler line, and the open area was closed with a stapler. The resected stapler lines were removed through the trocar using an endo bag. Following an air leakage test, the operation was terminated by placing a drain.

Figure 1 Extraction of the specimen from the rectal lumen.

Figure 2 Extraction of the specimen from the anal canal.

Potential pitfalls

Successful endoscopic derotation is required for laparoscopic surgery in patients with sigmoid volvulus. Even after successful derotation, exploration difficulties may occur due to the dilated colon. In some patients, a loose abdominal wall secondary to chronic dilatation may facilitate exploration (23). Because colotomy is required in patients who are planning to have the specimen removed by transanal route, colon cleansing before surgery is important. The risk of stool contamination is very low in colon specimen removal by the transvaginal route, as both ends of the colon are closed. However, stool contamination may occur because the colon is opened for transanal specimen extraction. Patience and caution are required in this regard. Natural orifice laparoscopic surgery is sometimes not possible, not just in debilitated, elderly patients with neuromuscular deficits, in whom sigmoid volvulus is common. Furthermore, laparotomy is inevitable in the presence of gangrene and in patients with unsuccessful endoscopic derotation.

Conclusions

In sigmoid volvulus patients, the absence of a mass and having a wider rectum compared with other patients may represent characteristics of the most appropriate patient group for NOSE.

Acknowledgments

Funding: None.

Footnote

Provenance and Peer Review: This article was commissioned by the Guest Editor (Cuneyt Kayaalp) for the series “Natural Orifice Specimen Extraction in Colorectal Surgery” published in Annals of Laparoscopic and Endoscopic Surgery. The article has undergone external peer review.

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://ales.amegroups.com/article/view/10.21037/ales-22-16/coif). The series “Natural Orifice Specimen Extraction in Colorectal Surgery” was commissioned by the editorial office without any funding or sponsorship. The authors have no other conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Sundin JA, Wasson D, McMillen MM, et al. Laparoscopic-assisted sigmoid colectomy for sigmoid volvulus. Surg Laparosc Endosc 1992;2:353-8. [PubMed]
2. Chung CC, Kwok SP, Leung KL, et al. Laparoscopy-assisted sigmoid colectomy for volvulus. Surg Laparosc Endosc 1997;7:423-5. [Crossref] [PubMed]
3. Liang JT, Lai HS, Lee PH. Elective laparoscopically assisted sigmoidectomy for the sigmoid volvulus. Surg Endosc 2006;20:1772-3. [Crossref] [PubMed]
4. Cartwright-Terry T, Phillips S, Greenslade GL, et al. Laparoscopy in the management of closed loop sigmoid volvulus. Colorectal Dis 2008;10:370-2. [Crossref] [PubMed]
5. Jacobs M, Verdeja JC, Goldstein HS. Minimally invasive colon resection (laparoscopic colectomy). Surg Laparosc Endosc 1991;1:144-50. [PubMed]
6. Stewart EA, Liau AS, Friedman AJ. Operative laparoscopy followed by colpotomy for resecting a colonic leiomyosarcoma. A case report. J Reprod Med 1991;36:883-4. [PubMed]
7. Franklin ME Jr, Ramos R, Rosenthal D, et al. Laparoscopic colonic procedures. World J Surg 1993;17:51-6. [Crossref] [PubMed]
8. Devane LA, Martin ST. Robotic sigmoid colectomy with transanal extraction - A video vignette. Colorectal Dis 2022;24:147-8. [Crossref] [PubMed]
9. Seow-En I, Chang SC, Ke TW, et al. Uncomplicated Sigmoid Volvulus Is Ideal for Laparoscopic Sigmoidectomy With Transrectal Natural Orifice Specimen Extraction. Dis Colon Rectum 2021;64:e90-3. [Crossref] [PubMed]
10. Chen MZ, Cartmill J, Gilmore A. Natural orifice specimen extraction for colorectal surgery: Early adoption in a Western population. Colorectal Dis 2021;23:937-43. [Crossref] [PubMed]
11. Sia TC, Cartmill J, Keshava A, et al. Natural orifice specimen extraction for high anterior resection - technical tips including an original and effective technique for atraumatic specimen extraction - a video vignette. Colorectal Dis 2019;21:849-50. [Crossref] [PubMed]
12. Hsieh YC, Lee JY, Chen YC, et al. Elective Laparoscopic Resection for Sigmoid Volvulus with Natural Orifice Specimen Extraction. Videoscopy 2019;29: [Crossref]
13. Wolthuis AM, de Buck van Overstraeten A, Fieuws S, et al. Standardized laparoscopic NOSE-colectomy is feasible with low morbidity. Surg Endosc 2015;29:1167-73. [Crossref] [PubMed]
14. Christoforidis D, Clerc D, Demartines N. Transrectal specimen extraction after laparoscopic left colectomy: a case-matched study. Colorectal Dis 2013;15:347-53. [Crossref] [PubMed]
15. D'Hondt M, Devriendt D, Van Rooy F, et al. Transvaginal pure NOTES sigmoid resection using a single port device. Tech Coloproctol 2014;18:77-80. [Crossref] [PubMed]
16. Hamada T, Hirose R, Kosaka T, et al. Laparoscopic sigmoidectomy using a prolapsing technique for sigmoid colon volvulus in children. Eur J Pediatr Surg 2010;20:50-2. [Crossref] [PubMed]
17. Xingmao Z, Haitao Z, Jianwei L, et al. Totally laparoscopic resection with natural orifice specimen extraction (NOSE) has more advantages comparing with laparoscopic-assisted resection for selected patients with sigmoid colon or rectal cancer. Int J Colorectal Dis 2014;29:1119-24. [Crossref] [PubMed]
18. Liu RJ, Zhang CD, Fan YC, et al. Safety and Oncological Outcomes of Laparoscopic NOSE Surgery Compared With Conventional Laparoscopic Surgery for Colorectal Diseases: A Meta-Analysis. Front Oncol 2019;9:597. [Crossref] [PubMed]
19. Izquierdo KM, Unal E, Marks JH. Natural orifice specimen extraction in colorectal surgery: patient selection and perspectives. Clin Exp Gastroenterol 2018;11:265-79. [Crossref] [PubMed]
20. Gundogan E, Aktas A, Kayaalp C, et al. Two cases of laparoscopic total colectomy with natural orifice specimen extraction and review of the literature. Wideochir Inne Tech Maloinwazyjne 2017;12:291-6. [Crossref] [PubMed]
21. Karagul S, Kayaalp C, Sumer F, et al. Success rate of natural orifice specimen extraction after laparoscopic colorectal resections. Tech Coloproctol 2017;21:295-300. [Crossref] [PubMed]
22. Khalayleh H, Koplewitz BZ, Kapuller V, et al. Neonatal sigmoid volvulus. J Pediatr Surg 2016;51:1782-5. [Crossref] [PubMed]
23. Raveenthiran V, Madiba TE, Atamanalp SS, et al. Volvulus of the sigmoid colon. Colorectal Dis 2010;12:e1-17. [PubMed]
